reFresh Full Size Units

reFresh Series

reFresh Standard Model

Model Features

  • Galvanized, 26 ga., insulated housing
  • Models with and without ES24V control
  • 6" round duct connectors
  • Integral backdraft damper
  • Test port for easy airflow measurement
  • 2" wide filter slot for optional 10 x 10 x 2" filters
  • Integral mounting tabs allow mounting in any orientation'
  • Backward inclined wheel
  • Speed controllable, AC or EC motor, 120V, 60 Hz
  • 4 pole, permanently lubricated, thermally protected motor
  • Internally mounted speed control to set required intake with high, medium, and low set points
  • Models with and without 6' power cord
  • EC motor models are ENERGY STAR® qualified and Ecowatt registered
  • AMCA Air and Sound Licensed
  • HVI Certified performance with and without optional MERV13 Filters
  • cULus 507 Listed
  • This product meets the requirements of Buy American (2009) and Build America, Buy America (BABA), as part of IIJA (2022). Download letter here.

AMCAcULusEcowattHVI2022 Energy StarBABA-ACT

Model Overview

All-in-one units to introduce fresh air from the outside into the residence. The reFresh series is specifically engineered to meet building and energy codes that call for ASHRAE 62.2 CFM requirements. The reFresh Full Size Units have set speeds at 40, 100, and 170 CFM (Low, Medium, and High).

These units feature high quality, efficient S&P backward inclined motorized AC or EC impellers. The full size units feature heavy-duty galvanized construction, integral metal duct collars designed for 6" round duct, and integral backdraft dampers. There are 8 model options with and without S&P's exclusive ES24V control and with or without 6' power cords. The Re-Fresh is designed for easy installation and maintenance, giving the homeowner the best IAQ solution in an all-in-one unit.

Applies to models without a "-P": Warning Icon WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

RF10-160EC, RF10-160EC-ES24V, RF10-160EC-P, and RF10-160EC-P-ES24V models are recognized as the Most Efficient of ENERGY STAR® 2023.

5-year warranty

Specifications without Filter

Model Duct Dia. CFM @ .2" SP (HVI Certified) Speed
(RPM at High Spd.)
Voltage/Frequency Current (Amps) at High Speed @ .2" SP Max SP Avg. Ship Weight (lbs)
Low Medium High
RF10-160AC 6" 50 100 180 2549 120V / 60Hz 0.60 .4" 23
RF10-160AC-ES24V 6" 50 100 180 2549 120V / 60Hz 0.60 .4" 24
RF10-160AC-P 6" 50 100 180 2549 120V / 60Hz 0.60 .4" 23
RF10-160AC-P-ES24V 6" 50 100 180 2549 120V / 60Hz 0.60 .4" 24
RF10-160EC 6" 40 100 170 2300 120V / 60Hz 0.54 .4" 23
RF10-160EC-ES24V 6" 40 100 170 2300 120V / 60Hz 0.54 .4" 24
RF10-160EC-P 6" 40 100 170 2300 120V / 60Hz 0.54 .4" 23
RF10-160EC-P-ES24V 6" 40 100 170 2300 120V / 60Hz 0.54 .4" 24

Specifications with Optional MERV13 Filters

Model Duct Dia. CFM @ .2" SP (HVI Certified) Speed
(RPM at High Spd.)
Voltage / Frequency Current (Amps) at High Speed @ .2" SP Max SP Avg. Ship Weight (lbs)
Low Medium High
RF10-160AC 6" 40 90 150 2510 120V / 60Hz 0.61 .4" 23
RF10-160AC-ES24V 6" 40 90 150 2510 120V / 60Hz 0.61 .4" 24
RF10-160AC-P 6" 40 90 150 2510 120V / 60Hz 0.61 .4" 23
RF10-160AC-P-ES24V 6" 40 90 150 2510 120V / 60Hz 0.61 .4" 24
RF10-160EC 6" 30 90 150 2300 120V / 60Hz 0.56 .4" 23
RF10-160EC-ES24V 6" 30 90 150 2300 120V / 60Hz 0.56 .4" 24
RF10-160EC-P 6" 30 90 150 2300 120V / 60Hz 0.56 .4" 23
RF10-160EC-P-ES24V 6" 30 90 150 2300 120V / 60Hz 0.56 .4" 24
Dimensional Drawing for the reFresh Standard Model

RF10-160AC/EC, RF10-160AC/EC-ES24V, RF10-160AC/EC-P, RF10-160AC/EC-P-ES24V

Note: ES24V control mounted on the interior of RF8 units.

Standard Accessories

DH6-120V In-line Duct Heater Submittal IOM
ES24V Envirosense Ventilation Control Submittal IOM
MD Motorized Backdraft Damper Submittal IOM
M8F10X10X2 MERV8 10x10x2" filter (single) for RF10 models Submittal
M13F10X10X2 MERV13 10x10x2" filter (single) for RF10 models Submittal
R24V General Purpose Switching Relay Submittal
